Horizontal Axially Split Case Centrifugal Pump

Short Description:

Purity PSC horizontal split case centrifugal pump features a volute design, an axially balanced impeller, and high-quality rolling bearings, ensuring stable and safe operation.

Send email to us

Product Detail

Product Tags

Product Introduction

Purity PSC horizontal split case centrifugal pump is designed with an axially split volute casing structure and a double-suction radial impeller, ensuring excellent hydraulic performance and stable operation. The axially split centrifugal pump body is available in two material options, AISI 304 stainless steel and HT250 cast iron, allowing it to adapt to different working conditions, including clean water supply, industrial circulation, and municipal applications.

Purity PSC centrifugal split case pump is equipped with grease-lubricated rolling bearings, which provide long-term sealing and reliable operation. The bearing system is designed to prevent liquid ingress, effectively protecting core components from contamination and damage. This design significantly reduces wear and tear, extends service life, and lowers maintenance and disassembly costs, making the axially split centrifugal pumps highly economical for long-term use.

Thanks to its robust construction and optimized hydraulic design, Purity PSC horizontal split case centrifugal pump delivers high efficiency, low vibration, and smooth operation even under heavy-duty conditions. The double suction impeller balances axial forces, improving stability and enhancing overall performance.

In addition, Purity PSC horizontal split case centrifugal pump offers flexible driving options and can be directly coupled with either an electric motor or a diesel engine. This wide compatibility makes it suitable for various applications, including industrial water supply, fire fighting systems, and large-scale water transfer projects.

Purity specializes in the production and manufacturing of industrial centrifugal pumps, providing customers with comprehensive water supply solutions. Purity has established cooperative relationships with clients in over 130 countries worldwide. Inquiries are welcome!
