PGWB Explosion proof horizontal single stage centrifugal pipeline pump

Short Description:

We are pleased to introduce the PGWB Explosion Proof Horizontal Single Stage Centrifugal In-Line Pump, a reliable and efficient pump designed for the safe transfer of flammable and explosive substances. The pump body of the pump is specially designed with explosion-proof materials to ensure the highest level of safety and reliability during operation.

Send email to us

Product Detail

Product Tags

One of the key features of the PGWB explosion proof pump is its versatility. It can be used to transport clear water and other liquids whose physical and chemical properties are similar to clear water. This makes it an invaluable asset in various industries such as energy, metallurgy, chemical, textile, paper, hotel and catering, where precise and efficient liquid transport is critical. Furthermore, it is ideally suited for boiler hot water pressurized transport and city heating system circulation pump applications, providing optimum performance and durability in these demanding environments.

PGWB pumps are also capable of handling a wide temperature range. The maximum medium temperature is TS100°C, which can effectively transport liquids even at extreme temperatures without affecting their performance. This makes it ideal for applications where temperature control is critical, ensuring optimal operation of the system.

In addition, PGWB series stainless steel pipeline chemical pumps are specially designed for transporting corrosive media without solid particles. Its rugged construction and corrosion-resistant properties make it perfect for the pressurized transfer of corrosive liquids. With an operating temperature range of -20°C to 100°C, it provides exceptional performance and durability in even the most challenging environments.

For the transportation of petroleum products, PGWB explosion-proof pumps are available as explosion-proof pipeline oil pump models. It is specially designed for transporting gasoline, kerosene, diesel and other petroleum products. Its temperature range of -20°C to 100°C ensures the safe and efficient transport of these volatile substances to meet the needs of the petroleum industry.

In a word, PGWB explosion-proof horizontal single-stage centrifugal pipeline pump is the best choice for handling flammable and explosive substances. Its explosion-proof material ensures the highest level of safety, while its versatility allows a wide range of applications. Whether transferring clean water, corrosive media or petroleum products, this pump delivers outstanding performance and reliability. Invest in a PGWB explosion proof pump today and experience the reliability and safety it offers.

working conditions

1.The pump system maximum pressure is 1.6MPa.that is to say the pump suction pressure + pump head <1.6MPa.(Please specify the system working pressure when) ordering, If pump system working pressure s greater than 1.6Ma,should be separately put forward when ordering, therefore we will use of steel materials to manufacture the over-current and connected parts of the pump.)
2.Medium:insoluble solids volume contents of no more than the volume per unit’s 0.1%. particle size less than 0.2mm.(f the medium contents of small particles, the wear-resistant mechanical seals is used.So please note it when ordering.)
3.The ambient temerature does not exceed 40′C, relative humidity is no more than 95%,altitude does not exceed 1000m.
4.PGLPGW Cod/Hot water centrifugal pumps is for conveying clean water or other liquids which physical properties are similar to water. Used in: energy. metallurgy, chemicals. textiles,paper.and hotels restaurants boiler and city heating system circulating pump.Medium temperature T≤100C.
5.PGLH/PGWH stainless steel centrifugal chemical pump is for conveying corrosive liquids that without solid particles.Medium temperature
-20C–~100C。
6.PGLB/PGWB explosion-proof centrifugal oil pump is for conveying petroleum products like gasoline,kerosene,diesel.Medium temperature
-20C–~100C。
