Single Stage Industrial Horizontal Split Case Fire Pump

Short Description:

Purity PSCM horizontal split case fire pump features double suction impeller, corrosion-resistant casing, and flexible sealing options for reliable performance.

Send email to us

Product Detail

Product Tags

Product Introduction

Purity PSCM horizontal split case fire pump adopts an axially split volute casing and a double suction radial impeller, allowing convenient access to internal components for inspection and servicing. The double suction impeller helps balance axial thrust, reduce vibration, and ensure smooth, stable performance under continuous duty. Purity PSCM electric split case fire pump casing and impeller are available in AISI 304 stainless steel or HT250 cast iron, providing flexible material selection for different media, pressure requirements, and installation environments.

Purity PSCM double suction fire pump body is manufactured from HT250 cast iron and treated with an anti-corrosion coating, improving resistance to moisture, and harsh operating conditions. This protective surface treatment helps prevent rust and corrosion, maintaining structural integrity and appearance over long-term use. Combined with a robust split case structure, the coated fire pump split case body enhances durability and makes the pump suitable for complex working environments where reliability and service life are critical.

In the sealing area, a shaft protection sleeve is provided to reduce wear and protect the shaft from damage caused by leakage or abrasive media. Purity PSCM fire pump horizontal split case can be equipped with either mechanical seals or packing seals, allowing users to select the most suitable sealing solution based on fluid properties, operating pressure, and maintenance preferences. This design helps minimize leakage risk, extend component service life, and reduce maintenance frequency.

Purity primarily manufactures industrial pumps and fire pumps, with a total production area of 60,000 square meters. In addition, Purity fire pumps have multiple independent production lines, and core components are produced and assembled by ourselves, giving them a significant price advantage. If you are looking for a reliable water pump manufacturer, Purity offers a guarantee of both product quality and competitive pricing. Welcome to contact us!
